Where Is the A/C Evaporator Located?

Reviewed by

Richard McCuistian, ASE Certified Master Automobile Technician

Technical Reviewer at CarParts.com

Written by CarParts.com Research Team - Updated on November 9th, 2023

Reading Time: 2 minutes

Summary

The A/C evaporator is also called the heat exchanger. This component is responsible for removing the heat from the air before it’s directed into the cabin.
You can typically find the evaporator inside a molded plastic casing behind the glove compartment, but typically the entire instrument panel needs to be removed for access to it.
Some vehicles have two evaporators, one in the instrument panel or at the vehicle’s front. The other one is typically at the vehicle’s rear behind a side panel or in the ceiling above the rear passengers.

Contents hide

1. Q: Where Is the A/C Evaporator Typically Located?

2. Tips on How to Access the A/C Evaporator

Q: Where Is the A/C Evaporator Typically Located?

A: The A/C evaporator is what engineers refer to as a “heat exchanger” that absorbs the heat from the air passing through its fins and tubes as the refrigerant evaporates inside the evaporator, removing humidity from the air before it is delivered through the air ducts to the cabin.

You can typically find the evaporator inside a moulded plastic casing behind the glove compartment, but typically the entire instrument panel needs to be removed for access to it.

Some models have two evaporators, one in the instrument panel or at the vehicle’s front. The other one is typically at the vehicle’s rear behind a side panel or in the ceiling above the rear passengers.

Tips on How to Access the A/C Evaporator

If you aren’t familiar with how to remove the entire instrument panel, it’s best not to even try this. Further, the refrigerant must be removed properly (never vent it to the atmosphere) before removing the evaporator. Always wear skin and eye protection when working around refrigerant systems.

Pro Tips are nuggets of information direct from ASE-certified automobile technicians working with CarParts.com, which may include unique, personal insights based on their years of experience working in the automotive industry. These can help you make more informed decisions about your car.

Pro Tip: This is not a job for DIY unless you’re very familiar with all the aspects of refrigerant systems and instrument panels. It’s not as easy as it would seem.
