P0560 Code: System Voltage

The charging system and battery voltage are monitored by your ride’s powertrain control module (PCM). P0560 is one of the several trouble codes related to an incorrect voltage concern. If your vehicle logs this code, you can learn more about it with this article.

What Does the P0560 Code Mean?

Diagnostic trouble code P0560 stands for “System Voltage.” The code is set when the PCM detects that battery voltage within a monitored circuit is not within specification.

The PCM keeps track of the system voltage to ensure everything is working as it should. It compares the actual voltage to the set ideal vehicle voltage level. If the PCM detects an abnormality in voltage levels, it logs code P0560.

Note: The definition of code P0560 can differ according to the vehicle manufacturer. Check the appropriate repair manual or repair database for the exact code definition.

What are the Common Causes of the P0560 Code?

• Failed system main relay or fuse
• Alternator failure
• Battery failure
• PCM failure
• Wiring Issue

What are the Common Symptoms of the P0560 Code?

• Illuminated check engine light
• Vehicle refuses to start
• Stalling

How to Diagnose the P0560 Code

DTC P0560 can be logged on various vehicles. However, this doesn’t mean that the steps for diagnosis and repair are the same for all vehicles.

If you’re not familiar with the system and vehicle repair in general, it might be best to have a mechanic diagnose the problem. But if you’re an experienced automotive DIYer, then you can go ahead and do the job yourself.  The video below will give you an idea of what the diagnostic process might involve:

How to Fix the P0560 Code

Fixing the P0560 isn’t easy. If you’re not familiar with automotive diagnostics, then we suggest taking your ride to a trusted mechanic.

However, if you have the tools and in-depth knowledge to get the job done, you can try and fix the problem yourself. However, keep in mind that there’s no universal solution for this error code. So it’s important to read up on vehicle-specific repair information.

Guides like the ones from Chilton can help you with your repair. You can also get an ALLDATA subscription to help you find vehicle-specific repair steps.

Where to Get Replacement Parts to Clear Code P0560

Don’t let your vehicle stay in the garage for long because of issues caused by the P0560 code. Look for the cause and deal with it promptly. If alternator failure or a dead battery is causing the problem, then get a high-quality replacement from CarParts.com as soon as possible.

We offer top-notch parts, so you can rest assured you’re getting a replacement that’s built to last. All our products pass strict quality checks from trusted industry professionals to ensure maximum durability and dependability.

Shopping on our website is also easy, thanks to our vehicle selector. It lets you input your car’s year, make, and model to ensure it only shows parts that fit your daily driver. You can then use our filters to refine the results further based on your preferred price range, brands, and more.

Our delivery process is also efficient thanks to our warehouses strategically located across the country. In fact, you can expect your new part to arrive at your doorstep in as fast as two business days if you place your order before noon.

Shop now and take advantage of our unbeatable deals for replacement parts!
