How to Replace Front ABS Sensor: 2009-2018 Dodge RAM 1500

Watch this video to learn how to replace the front ABS sensor on a 2009-2018 Dodge RAM 1500.

Replacing Front ABS Sensor on a 2009-2018 Dodge RAM 1500: What You Need

Ready to perform this DIY replacement job? Remember that all the parts in this guide can be found on CarParts.com. Check out all the products that fit your vehicle right here.

Parts Checklist

• ABS sensor
• Penetrating oil
• Contact cleaner

Tightening Torques

• Wheel speed sensor mounting bolt to Hub: 15 Ft-lbs
• Brake cliper mount bolts: 130 Ft-lbs

Tools Checklist

Here’s the toolbox we recommend to repair your Dodge RAM 1500: HM85 85 Piece Ratchet and Socket Set

List of tools:

• Hydraulic jack
• Jack stands
• Wheel lug wrench
• iron wire
• Ratchet
• 21mm socket
• Flat head screwdriver
• Wire brush
• 5mm Allen socket
• Torque wrench
  • 20 to 250 Ft-lbs
  • 100 to 600 Ft-lbs

Step-by-Step Instructions

Step 1: Turn off your engine and engage the parking brake.

Step 2: Loosen the stud bolts on the front wheels.

Step 3: Lift the front of your vehicle.

Step 4: Watch the video on “How to jack your RAM 1500 safely” before proceeding.

Step 5: Place the vehicle on jack stands.

Step 6: To change the front ABS sensor, remove the wheels for full access.

Step 7: Place the removed wheels under the vehicle.

Step 8: Remove the caliper assembly.

Step 9: Secure the assembly to the upper control arm using a wire.

Step 10: Unscrew the two screws from the caliper mount using a ratchet and a 21mm socket.

Step 11: Watch the video on “How to replace the front brake discs and brake pads RAM 1500?” for more information.

Step 12: Attach the assembly to the iron wire previously installed.

Step 13: Use a flat head screwdriver to pull the retainer away from the disc and remove the disc.

Step 14: Locate and inspect the ABS sensor.

Step 15: Use a ratchet and a 5mm Allen socket to unscrew the ABS sensor retaining screw.

Step 16: Remove the sensor by jiggling it back and forth.

Step 17: Unclip all retaining clips for the ABS sensor cable starting from the wheel knuckle.

Step 18: Unclip the ABS sensor cable retaining clip behind the mudguard.

Step 19: Disconnect the connector by pushing on the red plastic tab, prying the tab, and pulling it.

Step 20: Remove the cable from the last clip and move it aside.

Step 21: Spray contact cleaner on the connectors.

Step 22: Take the new cable and place it back in its upper slot, then reconnect it.

Step 23: Clip the ABS sensor connector back inside the mudguard.

Step 24: Clip the sensor into its various slots.

Step 25: Thread the sensor through the opening in the brake backing plate and insert it into its slot.

Step 26: Retighten the retaining screw and finish tightening using a torque wrench.

Step 27: Reinstall the brake disc and put the retainer back in place.

Step 28: Reinstall the caliper assembly and screw it back on.

Step 29: Finish tightening using a torque wrench.

Step 30: Remove the wire used to hold the caliper assembly together.

Step 31: Put the wheels back on your vehicle.

Step 32: Lower the car and block the wheels properly.

Step 33: Operation complete.

Compatible Vehicles

The operation and tools displayed in the video should be available on the following vehicles:

• 2009 Dodge Ram 1500
• 2010 Dodge Ram 1500
• 2011 Ram 1500
• 2012 Ram 1500
• 2013 Ram 1500
• 2014 Ram 1500
• 2015 Ram 1500
• 2016 Ram 1500
• 2017 Ram 1500
• 2018 Ram 1500

Important Reminder

Before installing the new sensor, we recommend that you thoroughly clean its location using fine sandpaper.
