2014 BRZ is only blowing air through main vents, not dash/floor/fogger. A/C is working properly and the temps chan Hvac Heater Blend Door Actuator

Question

miaalbright

2014 BRZ is only blowing air through main vents, not dash/floor/fogger. A/C is working properly and the temps chan Hvac Heater Blend Door Actuator

The power of the air is well controlled (low-med-high) and functioning
A/C is cold
Heat is hot
It will only blow out of the main vents though, not the top defog vents or the floor vents, regardless of mode or temp.
Noc licking sound can be heard. I think it's the bled door, bt i don't know how to easily diagnose this w/o going to mechanic.

Status: Open Dec 09, 2023 - 11:32 PM

Subaru

Comments (0) | New Comment

Do you have the same question? Follow this Question

Answer this question Report it

3answers

Voted Best Answer

gsmith81575

Dec 10, 2023 - 07:33 AM

The issue could indeed be related to an issue with the heater blend door or the blend door actuator. Here are some steps you can take to diagnose the problem and/or fix your issue.

Check for diagnostic trouble codes (DTCs, I'd start with this), check the mode selector control, listen for actuator Movement, inspect the blend door actuator, manually move the blend door to see if stuck, and performing a HVAC system reset be disconnecting the battery for a few minutes.

2

0

Report it

Comments (1) | New Comment

Answers

Grace_CarParts.com

Dec 11, 2023 - 11:47 PM

Hi there, Mia!

It seems like the issue with your 2014 Subaru BRZ could be related to the air distribution system, possibly the blend door actuator. The symptoms you've described, such as the air only blowing through the main vents and the sound of a clicking noise, are commonly associated with a faulty blend door actuator. While diagnosing this without professional help can be challenging, you can try the following steps:

Check the Blend Door Actuator: The clicking sound you hear could indicate a malfunctioning blend door actuator. You can try locating the actuator under the dashboard and observing its movement while adjusting the vent modes. If it's not moving properly, it may need to be replaced.
Inspect for Obstructions: Ensure no obstructions are blocking the vent openings or the blend door's movement.
Diagnostic Tool: Using a diagnostic tool that can interface with your car's HVAC system may provide more detailed information about the issue.

While some of these diagnostics can be done at home, considering the complexity of the HVAC system and the possibility of multiple issues, it's best to consult a qualified mechanic. They have the experience and tools to accurately diagnose the problem and recommend the appropriate repairs.

Remember, addressing these issues early on can help prevent further damage and costly repairs down the line.

2

0

Report it

Comments (0) | New Comment

Moeflood

Dec 20, 2023 - 11:20 PM

If your 2014 BRZ is only blowing air through the main vents and not the dash, floor, or defogger vents, it could indeed be related to an issue with the blend door or the HVAC system. Here are some steps you can take to diagnose the issue:

Check for Faulty Blend Door Actuator:
- The blend door actuator controls the direction of airflow. If it's faulty, it may not be directing the air to the desired vents. Listen for any clicking sounds near the dashboard when you change the vent settings. A clicking sound could indicate a malfunctioning blend door actuator.
Inspect Vacuum Lines:
- Some HVAC systems use vacuum-operated actuators. Check for any disconnected or damaged vacuum lines in the engine compartment that may affect the operation of the blend door.
Manual Control Test:
- Some vehicles allow you to manually move the blend door by reaching under the dashboard. Check your vehicle's service manual to see if this is possible for your BRZ.
Perform HVAC System Reset:
- Disconnect the car battery for a few minutes and then reconnect it. This may reset the HVAC system and recalibrate the blend door actuator.
Check HVAC Control Module:
- The issue could also be with the HVAC control module. Check for any error codes using a diagnostic scanner that can communicate with the HVAC system.
Professional Diagnosis:
- If the above steps don't identify the problem, consider seeking professional help. Mechanics can use advanced diagnostic tools to assess the blend door actuator and the overall HVAC system.

Keep in mind that accessing and repairing blend door actuators can vary in difficulty depending on the vehicle model. Some vehicles require removing parts of the dashboard for access. If you're not comfortable with the diagnosis or repair process, it's advisable to consult a professional mechanic who specializes in HVAC systems.

2

0

Report it

Comments (1) | New Comment
